| Model | HE-615 |
| Type | 15inch 2-way full range speaker |
| Drivers | LF: 1x15" speaker,190mm maganet, 75mm voice coil |
| HF: 1x1.75" Mylar diaphragm tweeter;horn | |
| Frequency Range | 53Hz-19KHz |
| Power handling capacity | 500W AES, 2000W Peak |
| Sensitivity | 98dB/1W/1m |
| Rated lmpedance | 8Ω |
| Max SPL | 123dB continue, 129dB peak |
| Coverage(H x V) | 50°-100° x 55°asymmetric horn |
| Construction | 13-layer,18mm birch plywood cabinet; |
| steel trill with water/dust proof acoustical spongia | |
| 14 x M8 fitting point, 38mm mounting hole ; hard black paint | |
| Dimensions | 430mm x 681mm x 448mm |
| Net Weight | 31Kg |
